ABSTRACT Quantum teleportation1 provides a ‘disembodied’ way to transfer quantum states from one object to another at a distant location, assisted by previously shared entangled states and a

classical communication channel. As well as being of fundamental interest, teleportation has been recognized as an important element in long-distance quantum communication2, distributed

quantum networks3 and measurement-based quantum computation4,5. There have been numerous demonstrations of teleportation in different physical systems such as photons6,7,8, atoms9,

ions10,11, electrons12 and superconducting circuits13. All the previous experiments were limited to the teleportation of one degree of freedom only. However, a single quantum particle can

naturally possess various degrees of freedom—internal and external—and with coherent coupling among them. A fundamental open challenge is to teleport multiple degrees of freedom

simultaneously, which is necessary to describe a quantum particle fully and, therefore, to teleport it intact. Here we demonstrate quantum teleportation of the composite quantum states of a

single photon encoded in both spin and orbital angular momentum. We use photon pairs entangled in both degrees of freedom (that is, hyper-entangled) as the quantum channel for teleportation,

and develop a method to project and discriminate hyper-entangled Bell states by exploiting probabilistic quantum non-demolition measurement, which can be extended to more degrees of

freedom. We verify the teleportation for both spin–orbit product states and hybrid entangled states, and achieve a teleportation fidelity ranging from 0.57 to 0.68, above the classical

limit. Our work is a step towards the teleportation of more complex quantum systems, and demonstrates an increase in our technical control of scalable quantum technologies. Access through

your institution Buy or subscribe This is a preview of subscription content, access via your institution ACCESS OPTIONS Access through your institution Subscribe to this journal Receive 51

print issues and online access $199.00 per year only $3.90 per issue Learn more Buy this article * Purchase on SpringerLink * Instant access to full article PDF Buy now Prices may be subject

to local taxes which are calculated during checkout ADDITIONAL ACCESS OPTIONS: * Log in * Learn about institutional subscriptions * Read our FAQs * Contact customer support SIMILAR CONTENT

BEING VIEWED BY OTHERS PROGRESS IN QUANTUM TELEPORTATION Article 24 May 2023 PROBABILISTIC TELEPORTATION OF A QUANTUM DOT SPIN QUBIT Article Open access 06 May 2021 THE EFFICIENCY OF QUANTUM

TELEPORTATION WITH THREE-QUBIT ENTANGLED STATE IN A NOISY ENVIRONMENT Article Open access 07 March 2023 REFERENCES * Bennett, C. H. et al. Teleporting an unknown quantum state via dual

classic and Einstein-Podolsky-Rosen channels. _Phys. Rev. Lett._ 70, 1895–1899 (1993) Article  ADS  MathSciNet  CAS  Google Scholar  * Briegel, H. J., Dur, W., Cirac, J. I. & Zoller, P.

Quantum repeaters: the role of imperfect local operations in quantum communication. _Phys. Rev. Lett._ 81, 5932–5935 (1998) Article  ADS  CAS  Google Scholar  * Kimble, H. J. The quantum

internet. _Nature_ 453, 1023–1030 (2008) Article  ADS  CAS  Google Scholar  * Gottesman, D. & Chuang, I. Demonstrating the viability of universal quantum computation using teleportation

and single-qubit operations. _Nature_ 402, 390–393 (1999) Article  ADS  CAS  Google Scholar  * Knill, E., Laflamme, R. & Milburn, G. J. A scheme for efficient quantum computation with

linear optics. _Nature_ 409, 46–52 (2001) Article  ADS  CAS  Google Scholar  * Bouwmeester, D. et al. Experimental quantum teleportation. _Nature_ 390, 575–579 (1997) Article  ADS  CAS

Google Scholar  * Marcikic, I., de Riedmatten, H., Tittel, W., Zbinden, H. & Gisin, N. Long-distance teleportation of qubits at telecommunication wavelengths. _Nature_ 421, 509–513

(2003) Article  ADS  CAS  Google Scholar  * Takeda, S., Mizuta, T., Fuwa, M., van Loock, P. & Furusawa, A. Deterministic quantum teleportation of photonic quantum bits by a hybrid

technique. _Nature_ 500, 315–318 (2013) Article  ADS  CAS  Google Scholar  * Krauter, H. et al. Deterministic quantum teleportation between distant atomic objects. _Nature Phys._ 9, 400–404

(2013) Article  ADS  CAS  Google Scholar  * Riebe, M. et al. Deterministic quantum teleportation with atoms. _Nature_ 429, 734–737 (2004) Article  ADS  CAS  Google Scholar  * Barrett, M. D.

et al. Deterministic quantum teleportation of atomic qubits. _Nature_ 429, 737–739 (2004) Article  ADS  CAS  Google Scholar  * Pfaff, W. et al. Unconditional quantum teleportation between

distant solid-state quantum bits. _Science_ 345, 532–535 (2014) Article  ADS  MathSciNet  CAS  Google Scholar  * Steffen, L. et al. Deterministic quantum teleportation with feed-forward in a

solid state system. _Nature_ 500, 319–322 (2013) Article  ADS  CAS  Google Scholar  * Wei, T. C., Barreiro, J. T. & Kwiat, P. G. Hyperentangled Bell-state analysis. _Phys. Rev. A_ 75,

060305(R) (2007) Article  ADS  MathSciNet  Google Scholar  * Nagali, E. et al. Optimal quantum cloning of orbital angular momentum photon qubits through Hong–Ou–Mandel coalescence. _Nature

Photon._ 3, 720–723 (2009) Article  ADS  CAS  Google Scholar  * Weinfurter, H. Experimental Bell-state analysis. _Europhys. Lett._ 25, 559–564 (1994) Article  ADS  CAS  Google Scholar  *

Pan, J.-W. et al. Multiphoton entanglement and interferometry. _Rev. Mod. Phys._ 84, 777–838 (2012) Article  ADS  Google Scholar  * Jacobs, B. C., Pittman, T. B. & Franson, J. D. Quantum

relays and noise suppression using linear optics. _Phys. Rev. A_ 66, 052307 (2002) Article  ADS  Google Scholar  * Kwiat, P. G. et al. Ultrabright source of polarization-entangled photons.

_Phys. Rev. A_ 60, 773–776 (1999) Article  ADS  Google Scholar  * Barreiro, J. T., Langford, N. K., Peters, N. A. & Kwiat, P. G. Generation of hyper-entangled photon pairs. _Phys. Rev.

Lett._ 95, 260501 (2005) Article  ADS  Google Scholar  * Mair, A., Vaziri, A., Weihs, G. & Zeilinger, A. Entanglement of the orbital angular momentum states of photons. _Nature_ 412,

313–316 (2001) Article  ADS  CAS  Google Scholar  * Hong, C. K., Ou, Z. Y. & Mandel, L. Measurement of subpicosecond time intervals between two photons by interference. _Phys. Rev.

Lett._ 59, 2044–2046 (1987) Article  ADS  CAS  Google Scholar  * Barreiro, J. T., Wei, T.-C. & Kwiat, P. G. Beating the channel capacity limit for linear photonic superdense coding.

_Nature Phys._ 4, 282–286 (2008) Article  CAS  Google Scholar  * Nagali, E. et al. Quantum information transfer from spin to orbital angular momentum of photons. _Phys. Rev. Lett._ 103,

013601 (2009) Article  ADS  Google Scholar  * Leach, J. et al. Quantum correlations in optical angle-orbital angular momentum variables. _Science_ 329, 662–665 (2010) Article  ADS  CAS

Google Scholar  * Fickler, R. et al. Quantum entanglement of high angular momenta. _Science_ 338, 640–643 (2012) Article  ADS  CAS  Google Scholar  * Hayashi, A., Hashimoto, T. & Horibe,

M. Reexamination of optimal quantum state estimation of pure states. _Phys. Rev. A_ 72, 032325 (2005) Article  ADS  Google Scholar  * Gühne, O. & Toth, G. Entanglement detection. _Phys.

Rep._ 474, 1–75 (2009) Article  ADS  MathSciNet  Google Scholar  * Żukowski, M., Zeilinger, A., Horne, M. A. & Ekert, A. “Event-ready-detectors” Bell experiment via entanglement

swapping. _Phys. Rev. Lett._ 71, 4287–4290 (1993) Article  ADS  Google Scholar  * D’Ambrosio, V. et al. Complete experimental toolbox for alignment-free quantum communication. _Nature

Commun._ 3, 961 (2012) Article  ADS  Google Scholar  * Graham, T. M., Barreiro, J. T., Mohseni, M. & Kwiat, P. G. Hyperentanglement-enabled direct characterization of quantum dynamics.

_Phys. Rev. Lett._ 110, 060404 (2013) Article  ADS  CAS  Google Scholar  * Slussarenko, S. et al. The polarizing Sagnac interferometer: a tool for light orbital angular momentum sorting and

spin-orbit photon processing. _Opt. Express_ 18, 27205–27216 (2010) Article  ADS  CAS  Google Scholar  * Andrews, D. L. & Babiker, M. (eds) _The Angular Momentum of Light_ (Cambridge

Univ. Press, 2012) * Jack, B. et al. Precise quantum tomography of photon pairs with entangled orbital angular momentum. _New J. Phys._ 11, 103024 (2009) Article  ADS  Google Scholar  * Pan,

J.-W., Gasparoni, S., Aspelmeyer, M., Jennewein, T. & Zeilinger, A. Experimental realization of freely propagating teleported qubits. _Nature_ 421, 721–725 (2003) Article  ADS  CAS

Google Scholar  * Zhang, Q. et al. Experimental quantum teleportation of a two-qubit composite system. _Nature Phys._ 2, 678–682 (2006) Article  ADS  CAS  Google Scholar  * Yin, J. et al.

Quantum teleportation and entanglement distribution over 100-kilometre free-space channels. _Nature_ 488, 185–188 (2012) Article  ADS  CAS  Google Scholar  * Bouwmeester, D. et al.

Experimental quantum teleportation. _Nature_ 390, 575–579 (1997) Article  ADS  CAS  Google Scholar  * Ma, X.-S. et al. Quantum teleportation over 143 kilometres using active feed-forward.

_Nature_ 489, 269–273 (2012) Article  ADS  CAS  Google Scholar  * Lu, C.-Y. & Pan, J.-W. Push-button photon entanglement. _Nature Photon._ 8, 174–176 (2014) Article  ADS  CAS  Google

Scholar  * Prevedel, R. et al. High-speed linear optics quantum computing using active feed-forward. _Nature_ 445, 65–69 (2007) Article  ADS  CAS  Google Scholar  Download references

ACKNOWLEDGEMENTS This work was supported by the National Natural Science Foundation of China, the Chinese Academy of Sciences and the National Fundamental Research Program (grant no.

2011CB921300). AUTHOR INFORMATION AUTHORS AND AFFILIATIONS * Hefei National Laboratory for Physical Sciences at Microscale and Department of Modern Physics, University of Science and

Technology of China, Hefei, 230026, Anhui, China Xi-Lin Wang, Xin-Dong Cai, Zu-En Su, Ming-Cheng Chen, Dian Wu, Li Li, Nai-Le Liu, Chao-Yang Lu & Jian-Wei Pan * CAS Centre for Excellence

and Synergetic Innovation Centre in Quantum Information and Quantum Physics, University of Science and Technology of China, Hefei, 230026, Anhui, China Xi-Lin Wang, Xin-Dong Cai, Zu-En Su,

Ming-Cheng Chen, Dian Wu, Li Li, Nai-Le Liu, Chao-Yang Lu & Jian-Wei Pan Authors * Xi-Lin Wang View author publications You can also search for this author inPubMed Google Scholar *

Xin-Dong Cai View author publications You can also search for this author inPubMed Google Scholar * Zu-En Su View author publications You can also search for this author inPubMed Google

Scholar * Ming-Cheng Chen View author publications You can also search for this author inPubMed Google Scholar * Dian Wu View author publications You can also search for this author inPubMed

 Google Scholar * Li Li View author publications You can also search for this author inPubMed Google Scholar * Nai-Le Liu View author publications You can also search for this author

inPubMed Google Scholar * Chao-Yang Lu View author publications You can also search for this author inPubMed Google Scholar * Jian-Wei Pan View author publications You can also search for

this author inPubMed Google Scholar CONTRIBUTIONS C.-Y.L. and J.-W.P. had the idea for and designed the research; X.-L.W., X.-D.C., Z.-E.S., M.-C.C., D.W., L.L., N.-L.L. and C.-Y.L.

performed the experiment; X.-L.W., M.-C.C., C.-Y.L. and J.-W.P. analysed the data; C.-Y.L. and J.-W.P. wrote the paper with input from all authors; and N.-L.L., C.-Y.L. and J.-W.P.

supervised the whole project. CORRESPONDING AUTHORS Correspondence to Chao-Yang Lu or Jian-Wei Pan. ETHICS DECLARATIONS COMPETING INTERESTS The authors declare no competing financial

interests. EXTENDED DATA FIGURES AND TABLES EXTENDED DATA FIGURE 1 HONG–OU–MANDEL INTERFERENCE OF MULTIPLE INDEPENDENT PHOTONS ENCODED WITH SAM OR OAM. A, Interference at the PBS where input

photons 1 and 2 are intentionally prepared in the states (orthogonal SAMs; open squares) and (parallel SAMs; solid circles). The _y_ axis shows the raw fourfold (the trigger photon t and

photons 1, 2 and 3) coincidence counts. The extracted visibility is 0.75 ± 0.03, calculated from _V_(0) = (_C_+ − _C_//)/(_C_+ + _C_//), where _C_// and _C_+ are the coincidence counts

without any background subtraction at zero delay for parallel and, respectively, orthogonal SAMs. The red and blue lines are Gaussian fits to the raw data. B, Two-photon interference on beam

splitter 1, where photons 1 and 4 are prepared in orthogonal OAM states. The black line is a Gaussian fit to the raw data of fourfold (the trigger photon and photons 1, 4 and 5) coincidence

counts. The visibility is 0.73 ± 0.03, calculated from _V_(0) = 1 – _C_0/_C_∞, where _C_0 and _C_∞ is the fitted counts at zero and, respectively, infinite delays. C, Two-photon

interference at beam splitter 2, where input photons 1 and 5 are prepared in the orthogonal OAM states. The black line is a Gaussian fit to the data points. The interference visibility is

0.69 ± 0.03 calculated in the same way as in B. Error bars, 1 s.d., calculated from Poissonian counting statistics of the raw detection events. EXTENDED DATA FIGURE 2 A UNIVERSAL SCHEME FOR

TELEPORTING _N_ DOFS OF A SINGLE PHOTONS. A, A scheme for teleporting two DoFs of a single photon using three beam splitters, which is slightly different from the one presented in the main

text using a PBS and two beam splitters. Through the first beam splitter, six asymmetric states, and , can result in one photon in each output, which is ensured by teleportation-based QND on

the Y DoF. After passing the two photons through the two filters that project them into the and states for the X DoF, four states, and , survive. Through the second beam splitter, only the

asymmetric state of the Y DoF can result in one photon in each output. Finally we can discriminate the state from the 16 hyper-entangled Bell states. B, Teleportation of three DoFs of a

single photons (Methods). Note that to ensure that there is one and only one photon in the output of the first beam splitter, we can use the teleportation-based QND on two DoFs in A (dashed

circle). C, Generalized teleportation of _N_ DoFs of a single photons. The h-BSM on _N_ DoFs can be implemented as follows: (1) the beam splitter post-selects the asymmetric hyper-entangled

Bell states in _N_ DoFs which contain an odd number of asymmetric Bell states in one DoF, (2) two filters and one bit-flip operation erase the information on the measured DoF and further

post-select asymmetric states, and (3) teleportation-based QND. EXTENDED DATA FIGURE 3 ACTIVE FEED-FORWARD FOR SPIN–ORBIT COMPOSITE STATES. A, The active feed-forward scheme. This composite

active feed-forward could be completed in a step-by-step manner. First, we use an EOM to implement the active feed-forward for SAM qubits. It is important to note that EOM does not affect

OAM. Second, we use a coherent quantum SWAP gate between the OAM and SAM qubits. The original OAM is converted into a ‘new’ SAM, whose active feed-forward operation is done by a second EOM.

Then the OAM and SAM qubits undergo a second SWAP operation and are converted to the original DoFs. B, The quantum circuit for a SWAP gate between the OAM and SAM qubits. The SWAP gate is

composed of three CNOT gates: in the first and third CNOT gates, the SAM and OAM qubits act as the control and target qubits, respectively, whereas in the second CNOT gate this is reversed.
