ABSTRACT Cells continuously exert or respond to mechanical force. Measurement of these nanoscale forces is a major challenge in cell biology; yet such measurement is essential to the

understanding of cell regulation and function. Current methods for examining mechanical force generation either necessitate dedicated equipment or limit themselves to coarse-grained force

measurements on the micron scale. In this protocol, we describe stimulated emission depletion traction force microscopy—STED-TFM (STFM), which allows higher sampling of the forces generated

by the cell than conventional TFM, leading to a twofold increase in spatial resolution (of up to 500 nm). The procedure involves the preparation of functionalized polyacrylamide gels loaded

with fluorescent beads, as well as the acquisition of STED images and their analysis. We illustrate the approach using the example of HeLa cells expressing paxillin-EGFP to visualize focal

adhesions. Our protocol uses widely available laser-scanning confocal microscopes equipped with a conventional STED laser, open-source software and common molecular biology techniques. The

entire STFM experiment preparation, data acquisition and analysis require 2–3 d and could be completed by someone with minimal experience in molecular biology or biophysics. Access through
